K-Span Curved Roll Forming Machine
- Product Description
Model No.: SF-M021
Brand: SUF
Packaging: NAKED
Productivity: 500 SETS
Transportation: Ocean, Land, Air, by train
Place of Origin: CHINA
Supply Ability: 500 SETS
Certificate: ISO 9001 / CE
HS Code: 84552210
Port: TIANJIN, XIAMEN, SHANGHAI
Payment Type: L/C, T/T, D/P, Paypal, Money Gram, Western Union
Incoterm: FOB, CFR, CIF, EXW, FCA, CPT, CIP
- Selling Units:
- Set/Sets
- Package Type:
- NAKED
Technical Parameters:
1. Coil width: 914mm
2. Output speed: 12 – 15m/min
3. Coil thickness: 0.6 – 1.5mm
4. Tolerance: 3m±1.5mm
5. Roller station: 17 stations
6. Main motor power: 11kw
7. Hydraulic oil pump motor: 5.5kw
8. The pressure of hydraulic: 12Mpa
9. Curving Machine power: 5kw+1.5kw (two), Locking machine power: 0.85kw
10. Frequency inverter: Panasonic
11. Computer control system, PLC control length, encoder: Omron
12. Diameter of roller: 75
13. Material of roller: Gcr15
14. Material of cutter: Cr12Mov, heat treatment HRC 58 – 62, chrome coating
15.Transmission type: 1 inch double chain drive
16. Main machine dimension: 8.5m*1.4m*1.4m
17. Material of blade: GCR12 with heat treatment
