Drywall Metal Stud And Track Furring Forming Machine
- Product Description
Model No.: SUF
Brand: SUF
Shaft Diameter: 40mm
Control System: PLC
Thickness: 0.3-0.8mm
Certification: ISO9001
Customized: Customized
Condition: New
Control Type: Other
Automatic Grade: Automatic
Drive: Hydraulic
Shaft Material: 45# Forged Steel
Roller Stations: 10
Main Power: 4.0kw
Forming Speed: 0-40m/min
Driven: Gear Box
Hydraulic Station: 3.0kw
Packaging: Naked
Productivity: 500 sets
Transportation: Ocean
Place of Origin: Hebei
Supply Ability: 500 sets
Certificate: ISO / CE
HS Code: 84552210
Port: Tianjin
Payment Type: L/C, T/T, Paypal, Money Gram, Western Union
Incoterm: FOB, CFR, CIF, EXW, FCA
- Selling Units:
- Set/Sets
- Package Type:
- Naked
Drywall Metal Stud And Track Furring Forming Machine
The Light steel keel roof produced by our Metal Stud And Track Forming Machine with good bending compression performance, flatness is good, automatic fixed length cutting, automatic punching, high degree of automation, fast and convenient installat
(1 machine for multi-profiles, size-changing by spacers)
The advantages of Drywall Roll Forming Machine are follows:
① The speed can reach 40-80m/min,
② Enlarged hydraulic station to ensure high speed working,
③ Easy operation, low maintenance cost,
④ Beautiful appearance,
⑤ One machine for multi-profiles, size-changing by spacer.
2. Detailed images of Metal Stud And Track Forming Machine
Machine Parts:
(1) Metal Furring Roll Forming Machine
Brands: SUF, Original: China
Feeding Guide (make feeding smooth and no wrinkling)
(2) Drywall Metal Stud And Track Furring Forming Machine
Rollers manufactures from hong life mold steel Cr12=D3 with heat treatment, CNC lathes,
Heat treatment (with black treatment or hard-chrome coating for options),
With feeding material guide, body frame made from 400# H type steel by welding.
(3) Hat Furring light keel forming machine straighting and logo punching device
Drywall Metal Stud And Track Furring Forming Machine
Omega Profile Light Keel Forming Machine operation panel
(5) Light Steel Keel Forming Machine servo track non-stop cutting
Made by high quality long life mold steel Cr12Mov with heat treatment,
Cutter frame made from high quality 30mm steel plate by welding,
Hydraulic motor: 5.5kw, Hydraulic pressure range: 0-16Mpa.
(6) Omega profile light steel keel forming machine Hydraulic System
Englarged hydraulic station to ensure high speed working
(7) Omega profile light steel keel forming machine Decoiler
Manual Decoiler: one set
Un-powered, manually control steel coil inner bore shrinkage and stop,
Max feeding width: 500mm, Coil ID range: 508±30mm,
Capacity: Max 3 tons.
With 3 tons hydraulic decoiler for option
(8) Hat Furring Light Keel Forming Machine exit rack
Un-powered, 4 meters long, one set
Other detailes of Omega profile light steel keel forming machine
Suitable for material with thickness 0.3-0.8mm,
Shafts manufactures from 45#, main shaft diameter 75mm, precision machined,
Motor driving, gear chain transmission, 12 rollers to form,
Main servo motor: 2.0kw, frequency speed control,
Forming speed: 40 / 80m/min as optional.
Product Categories : Cold Roll Forming Machine > Light Keel Roll Forming Machine
