Cable tray Lintel Roll Forming Machine
- Product Description
Model No.: SF-307
Brand: SENUF
Place Of Origin: China
Species: Ladder Tray, Solid Through, Ventilated Or Perforated Trough
Material: Steel, Pvc, Frp, Carbon Steel
Certification: CE
Hole: with Hole
Feature: Corrosion Resistance
Surface Treatment: Hot Galvanizing
Type: Tray
Packaging: many kinds packing as customers demand
Productivity: 50Tons/ 8 hours
Transportation: Ocean, Land, Air
Place of Origin: hebei china
Supply Ability: 500 SETS
Certificate: ISO9001
HS Code: 84552210
Port: Tianjin, Shanghai, Ningbo
Payment Type: L/C, T/T, D/P, Paypal
Incoterm: FOB, CFR, CIF, EXW, FCA, CPT, CIP
- Selling Units:
- Set/Sets
- Package Type:
- many kinds packing as customers demand
Steel channel lintel cable tray is a structural horizontal block that spans the space or opening between two vertical supports. It can be a decorative architectural element, or a combined ornamented structural item. It is often found over portals, doors, windows and fireplaces. All lintels are produced by Galvanized steel or Stainless steel, it make the construction system more and more strong.
IN PARAMETER
Decoiler with straightener
Width：≤456mm
Thickness:≤3.2mm
Inner diameter: 450-530mm
Max loading weight:2T
Rollers of straightener: 7 rollers
Punching machine
Width:≤456mm
Thickness:≤3.2mm
Material:Mild steel
Punching force:125T
Power:15KW
Forming machine and Hydraulic cutting
Roller number: 11 sets
Drive type:Gear drive
Diameter of forming rollers:φ75m
Speed: 10-20 m/min
Material of forming rollers:Gcr15
Hardness :HRC58-62°
Main motor:11Kw.control by frequency converter
Hydraulic cutting
Cutting type:hydraulic cutting
Pump:7.5Kw
Cutting according to the setting length
Collecting Table
